Sismografo Ambrogeo Echo24: caratteristiche tecniche
Ambrogeo Echo24/2002 Seismic UNIT
| Number of channels | 24 |
| Sampler interval | 0,296 msec |
| A/D Conversion | 16 bit |
| Amplifiers | |
| Input impedance | 1 KOhm |
| Gain | 10 dB - 100 dB, step 1 dB |
| Saturation tension | +/- 2,3 V |
| Saturation level | 100 dB |
| Distorsion | 0,01% |
| Sampler | 25 msec (191 points) |
| 50 msec (383 points) | |
| 100 msec (756 points) | |
| 200 msec (1530 points) | |
| 400 msec (3060 points) | |
| 800 msec (6121 points) | |
| Sampling | 130 micro/sec |
| Record lenght | 25-50 -10 -20 -400-800 millisec |
| Filter low pass | from 50 to 950 Hz, step1 Hz |
| Digital Filter (Fir) low pass | 1000-900-800-700-600-500-400-300-200-100-50 Hz |
| Digital Filter (Fir) high pass | 0-25-50-75-100-125-150-175-200-225-250 Hz |
| Frequency response | 7-950 Hz, filter at 950 Hz |
| Dynamic range | 93 dB |
| Noise | 0,66 uV rms, gain = 55 dB |
| Crosstalk | 52 dB, gain = 55 dB |
| Power | 12 W |
